Welcome to Diagram3D

Diagram3D designs and produces kits for scale model railway vehicles. The kits are produced using innovative techniques and modern technology. The kits are laser cut in card, MDF or wood and can be assembled without soldering. The assembly instructions can be freely downloaded from this website. We don't mind sharing information and have a download section for interesting prototype information which has been gleaned from various sources.

Making models of historical railway vehicles can be frustrating. The prototypes often had complicated panels and details. Reliable historical information can be difficult to find. Producing a set of vehicles from scratch can be a daunting prospect.  Our intention is to reduce this frustration and save your valuable modelling time. Each of our kits will assemble into an accurate body shell which can then be used to produce a detailed model.

The results can be impressive. Visit our gallery for images of completed models and details of construction. Save your time by using our products.
Assembly

Our model kits are easy to assemble without specialist skills.

Nevertheless our kits can give outstanding results while saving valuable time. They save your time and effort, enhancing your skills and abilities. The YouTube video shows a a kit being assembled.

Assembly instructions for our products can be downloaded from the product page.

Clear, illustrated instructions

GNR D303 Full Break All our products contain clear instructions which are available for download (in PDF format) from this website.

 Read the instructions before buying and there will be no hidden surprises when you order. The instructions include illustrations like the one shown above .

We aim to make the assembly process as  pain free and efficient as possible.

Historic information is included. For example,  livery details and numbers are included. Hints and timing of the stages is included as an aid to help plan the project.

Click on this link to view an example of the instructions for our kits : PDF instructions for 4mm kit GN04-D303

Click here  GN04-D303 to be taken to the product description for this kit.

GNR Parcels Fruit and Milk Van

The GNR produced a small number of six wheeled parcels fruit and milk vans to diagram 331. Some of these vehicles survived to be renumbered as LNER vehicles. The vans featured a clerestory roof. This model is an unusual and interesting addition to a layout.  GN04-D331 Parcel Fruit & Milk Van

"OO" gauge wheels & Mansell inserts

These metal "OO" disc wheels are approximately a scale 3ft 5in in diameter, excluding the flanges. The wheels are suitable for use with our coach kits. The inserts give an effective represenation of a Mansell pattern wooden centered wheel.  D3D-01 conatins Three axles and six Mansell pattern inserts. This is sufficient for one six wheeled vehicle. click here D3D-01 3 axles Mansell WheelsD3D-02 conatins Four axles and eight Mansell pattern inserts. This is sufficient for an eight wheeled vehicle. click here D3D-02 4 axles Mansell Wheels

"OO" Wheels, 3 axles & Mansell inserts"OO" Wheels, 3 axles & Mansell inserts4 axxles "OO" with mansell wheel inserts

North Eastern Railway (NER) 32ft carriages - Guards Vans

NE04-D021 assembled The North Eastern Railway produced 32ft six wheeled carriages in large numbers to a standard design until the late 1890's. These carriages were intended to replace older designs. Our models of these carriages now include a Guards Van with two 3d class compartments (diagram 20)  Click here NE04-D020 Van thrid



 The models feature a detachable roof and are based on original drawings and reference material.

Another model available now is the Guards Van (full brake),diagram 20, NE04-D021 Van

NE04-D021 assembled

NE04-D021 assembly

North Eastern Railway (NER) 32ft carriages - First & Composite

NE04-D068 assembled The North Eastern Railway produced 32ft six wheeled carriages in large numbers to a standard design until the late 1890's. These carriages were intended to replace older designs. Our models of these carriages now include a first class carraige (Diagram 68)  Click here NE04-D068 to see the product.

 The models feature a detachable roof and are based on original drawings and reference material.

Another model available now is the luggage composite,diagram 9, NE04-D009 with more models to follow.

NE04-D009 assembled

NE04-D009 assembly

North Eastern Railway (NER) 32ft carriages: Third and Luggage Third

NE04-D015 assembled The North Eastern Railway produced six wheeled carriages in large numbers to a standard design until the late 1890's. The most numerous of these was the five compartment third class carriage (diagram 15).

Our model of this model features a detachable roof and is based on original drawings and reference material. Click here NE04-D015 to see the product.

A companion model available now is the luggage third,diagram 13, NE04-D013 with more models to follow.

NE04-D013 assembled

NE04-D015 assembly

GN04-D281 GNR six wheeled brake carriage

GNR D281 third class brakeGreat Northern Railway (GNR) Diagram 281 (D281) Third Class Brake:

This vehicle was an ubiquitous vehicle produced by the GNR.. Approximately 370 of this type were included in the stock inventories at the beginning of the 20th century.

Click on the image or here to see the product details:GN04-D281

Click here to see this model in our gallery: Gallery GN04-D281Similar vehicles were used by the East Coast Joint Stock (ECJS).

One of These coaches, number 589,  has been preserved at the Keighley Worth Railway.GNR D281 third class brake

GN04-D129 45ft Composite Coach

 GN04-D129 45 foot Composite Coach This 45 foot coach built to diagram 129 (D129) was one of several similar vehicles which were designed by Howlden for the GNR in the 1890’s..

The vehicle combined an open third class area and separate first class accommodation.

This vehicle is described in “Historic Carriage Drawings” Volume 1 by N. Campling. ISBN 1 899816 04 6 page 94. One of these coaches has been preserved and is stored at the Keighley Worth Valley Railway.

These vehicles lasted well into the grouping period and travelled extensively over the rail system after grouping.

 Click on the image or here: GN04-D129 to link to the product page
